Key Features
5-Axis Continuous Machining
Travel: X-axis: 762mm, Y-axis: 460mm, Z-axis: 460 mm, A-axis: -20° to +110°, C-axis: 360°
Rapid Traverse Speeds: X & Y axis: 40 m/min, Z axis: 32 m/min
Motor Spindle: VAC integral motor spindle, 22/18.5 kW, capable of 15,000 rpm for high-speed machining
High Torque: 199 Nm at 720 rpm for robust performance on tough materials
Coolant Supply: 70bar coolant flow through the spindle
Thermal Stabilization:
TAS-S (Thermo Active Stabilizer – Spindle): System for compensating spindle distortion due to heat.
TAS-C (Thermo Active Stabilizer – Construction): Ensures machine body stability under temperature fluctuations.
Precision: High accuracy positioning with X: 1.7 µm, Y: 2.4 µm, Z: 2.2 µm according to ISO230-2
Tool Magazine: Automatic tool changer (ATC) with a capacity of 32 tools, with a fast 1.2 seconds tool change time
Super NURBS: High-speed NC function for smooth surface machining with reduced vibration
RTCP II: Tool Center Point Control, tool posture compensation
Auto Tuning: Geometric Error Compensation – Automated error correction for precise machining
X, Y, Z, B, C axis with absolute linear encoders, 0.001mm at 150m/min
Trunnion table with Hypoid gear transmission and direct absolute measurement
Spindle coolant through system with 70bar pressure for special drilling
Interactive work gauging software, Metrology cycle via Renishaw probe
Renishaw Touch Probe-Kit & Renishaw tool setter
